M2-6

The EAPL M2-6 is a reliable six-channel sequential timer designed for precise, step-by-step control of multiple electrical loads. Each channel operates with independently adjustable ON and OFF durations, allowing for flexible and efficient automation of motors, pumps, fans, or process equipment. With advanced timing control, multiple operating modes, and a compact industrial-grade design, the M2-6 ensures smooth, non-overlapping operation, protecting equipment from inrush current and optimizing process sequencing.

Key Features:

• Six independent output channels with individually programmable ON and OFF times.

• Adjustable time range from 0.1 seconds to 99 hours 59 minutes per channel.

• Two operating modes: Single-Cycle Mode (one full sequence) or Cyclic Mode (automatic repetition).

• Selectable HOLD or RESTART mode after power restoration.

• Start input (S1–S2) for external trigger and Pause input (I1–I2) for halting mid-sequence.

• Cycle-complete output for signaling process completion or system feedback.

• Wide operating voltage range: 85 – 270 V AC/DC.

• Rugged, panel-mountable construction suitable for industrial environments.

Applications:

• Sequential control of motors, pumps, fans, or compressors.

• Dust-collector and ventilation systems requiring timed start-stop cycles.

• Conveyor, packaging, and process machinery needing sequential activation.

• MCCs and control panels where load sequencing improves safety and efficiency.
