H1DT-10

H1DT-10 – Product Description

• The H1DT-10 is a digital multifunction timer designed for precision control in industrial automation.

• Provides multiple timing functions such as ON-delay, OFF-delay, Interval, and Cyclic.

• Features a digital display for accurate time setting and monitoring.

• Compact panel-mounted design with user-friendly keypad and clear LED indicators.

• Built for reliable performance in automation, MCCs, and process control panels.

Key Specifications

• Function: Digital multifunction timer (ON-delay, OFF-delay, Interval, Cyclic, etc.).

• Supply Voltage: Wide operating range (typically 100–240 V AC and 24 V DC models available).

• Time Range: Adjustable from 0.1 seconds to 999 hours depending on the selected range.

• Output: 1 C/O (Change-over) or 2 C/O relay contacts (depending on version), rated 5 A at 250 VAC / 28 VDC resistive load.

• Display: Digital LED/LCD display for time setting and countdown indication.

• Power Consumption: Low, typically ≤5 VA.

• Accuracy:

  • Setting accuracy: ±0.1% of set time.

  • Repeat accuracy: ±0.05%.

• Control Inputs: Start, reset, and gate inputs for flexible control.

• Indicators: LED indicators for power and output status.

• Environmental Ratings:

  • Operating temperature: –10 °C to +55 °C.

  • Storage temperature: –25 °C to +80 °C.

  • Humidity: Up to 85–95% RH at 40 °C.

• Service Life:

  • Mechanical: ≥10 million operations (no load).

  • Electrical: ≥100,000 operations at rated load.

• Mounting: Panel-mounted with standard 48 × 48 mm size.

• Dimensions: Approx. 48 mm × 48 mm × 100 mm.

Applications

• Sequential motor control in MCCs.

• Pumps, compressors, and fans requiring programmable ON/OFF cycles.

• Packaging, textile, and process machinery for timed automation.

• Lighting and heating systems with programmable delays.

• Transformer and DG set control requiring accurate timing.

• General automation systems needing flexible multifunction timing.

Summary

• The H1DT-10 is a reliable digital multifunction timer with wide timing ranges (0.1 s to 999 h).

• Offers high accuracy, repeatability, and versatile timing modes.

• Features a compact 48 × 48 mm design with digital display and easy programming.

• Ideal for industrial automation, MCCs, control panels, and process industries where precise and flexible timing is critical.
